From Decoration to Interaction
How SEEKINK’s Full-Color Spliced Prism E ink Wall Makes Spaces “Speak”?
At SEEKINK, we’ve spent 3 years redefining what walls can do. Today, we’re proud to introduce “Prism Tiling ePaper Wall”—not just a surface, but a dynamic canvas that transforms spaces into living, interactive experiences. This isn’t just decor; it’s a revolution in spatial intelligence.
SEEKINK’s Spliced Prism E ink Wall tech at a glance
Powered by Prism 3S: We utilize our proprietary full-color ePaper film, which allows for dynamic & changeable vibrant colors & patterns.
Seamless by Design is being optimized: ≤5mm narrow edge design bezels + smart pixel algorithms create flawless large-scale displays.
Ultra-Efficient: A 10m² wall runs on a single power bank thanks to our distributed drivers. (0 power consumption during static screen maintenance)
Your Canvas, Your Control: Our Prism App (iOS/Android) lets you upload art, collaborate in real-time, and adapt spaces instantly.
Specification
Full-Color Spliced Prism E ink Wall Module
| EPD | Module No. | R209E6B01 |
| Size | 21 inch | |
| Color | black, white, red, yellow,blue,green | |
| Type | Prism 3S | |
| Number of segments | 640 | |
| Aspect Ratio | 5:2 | |
| RF parameters | Transmission frequency band | 2400MHz-2483.5 MHz |
| Transmission tool | Android application | |
| Distance | 10m | |
| Frequency offset | ±20kHz | |
| Transmission power | 6dBm | |
| Bandwidth | 2MHz | |
| Sensitivity | -94dBm | |
| Power | Power supply | USB type-C |
| Input voltage | 5V | |
| Static current | Average 0.5mA | |
| Work current | Average 5mA | |
| Software | Refresh Method | Refresh by Android phone APP: The best transmission distance between phones and devices is within 10m |
| Phone operating system | Android（Version 8.0 and above） |
More about the Full-Color Spliced Prism E ink Wall
Why We Built It?
“We saw walls as wasted potential—static, silent, and energy-hungry. Prism changes everything.”
- World’s First Scalable ePaper Wall: We shattered size/color barriers that limited ePaper for decades.
- Zero Static Power: Consumes 1/1000th the energy of LED displays (0W when idle).
- Designed for Real Life: From homes to retail, walls now adapt with you—not against you.
Behind the Breakthrough
In 2022, our team asked: “What if walls could think?” Skeptics called it impossible. Back then, ePaper was small and monochrome. We cracked these key challenges:
- Material Science: Engineered ultra-thin (<1mm), lightweight (<200g) color modules.
- Invisible Seams: 5mm narrow edge design & intelligent pixel compensation algorithm to realize the wall display as one.
- Simplified Power: No heavy wiring—just sustainable scalability.
Transform Spaces with Us
- Homes: Shift from alpine mornings to nebula nights in one tap.
- Workplaces: Turn conference walls into agile project hubs or zen retreats.
- Retail: AI-driven displays that boost engagement 24/7—ZERO energy waste.
- ……
Our Sustainability Promise
- Prism isn’t just smart—it’s responsible:
- Saves ~3,000 kWh/month per 10m² (vs. LED).
- Zero light pollution. Zero blue light. Zero compromise.
What’s Next? We will explore:
- Curved ePaper Walls: Free spaces from flat constraints.
- AI Co-Creation: Walls that learn your style and generate art on-demand.
- Touch-Interactive Surfaces: Turn entire rooms into collaborative canvases.
- ……
“We’re not decorating walls—we’re giving them a voice.
And they’re just starting to speak.”
Our Vision
3 years ago, this was a dream. Today, Prism proves walls can be alive, adaptive, and kind to our planet.
At SEEKINK, we see spaces not as boundaries—but as conversations waiting to happen.
Join us as we rewrite the future, one intelligent surface at a time.
